Error Handling in RxJS



Take this little RxJS snippet: It looks up abilities of a given Pokémon in the PokéAPI and logs the results to the console:

1import { ajax } from 'rxjs/ajax'; // @see [RxJS](https://learnrxjs.io)

2import { BehaviorSubject } from 'rxjs'; // @see [RxJS](https://learnrxjs.io)

3import { switchMap } from 'rxjs/operators'; // @see [RxJS](https://learnrxjs.io)

4

5const POKE_API = 'https://pokeapi.co/api/v2/pokemon/';

6

7const name = new BehaviorSubject('charizard'); // --> Represents the name of the Pokémon

8name.pipe(switchMap(name => ajax.getJSON(POKE_API + name + '/'))) // --> Request the API

9.subscribe(d => // --> For each response ...

10 console.log(

11 `${d.name}:: ` + // --> ... Log the name of the Pokemon ...

12 `${d.abilities.map(a => a.ability.name).join(', ')}` // --> ... And their abilities

13 )

14);

Try It!

To utilize it, we can for example feed Pokémon names directly into the name subject:

1setTimeout(() => name.next('snorlax'), 1000); // --> Let's have a timeout so data is requested one by one

2setTimeout(() => name.next('eevee'), 3000); // --> Let's have a timeout so data is requested one by one

3

4// Result:

5// > charizard:: solar-power, blaze

6// > snorlax:: gluttony, thick-fat, immunity

7// > eevee:: anticipation, adaptability, run-away

Or we can bind the name subject to an HTML input so that we get an interface for our nice console tool:

1/** @jsx renderer.create **/

2import { Renderer } from '@connectv/html'; // @see [CONNECTIVE HTML](https://github.com/CONNECT-platform/connective-html)

3

4const renderer = new Renderer(); // --> The `Renderer` class helps us render HTML elements

5renderer.render(<input _state={name}/>).on(document.body); // --> Render an input whose state is bound to `name`


Either way, our code snippet works pretty fine for correct Pokémon names and logs their abilities to the console.

But what happens when we accidentally feed name a non-existing Pokémon name?

1setTimeout(() => name.next('snorlax'), 1000); // --> snorlax info is fetched

2setTimeout(() => name.next('ZZZ'), 1000); // --> ZZZ does not exist

3setTimeout(() => name.next('eevee'), 3000); // --> eevee info is also not fetched!

4

5// Result:

6// > charizard:: solar-power, blaze

7// > snorlax:: gluttony, thick-fat, immunity

8// No more logs


Nothing was logged for 'ZZZ', which is not unexpected since we do not have any code to handle errors, and since 'ZZZ' is not a correct Pokémon name, it naturally gets an error from the PokéAPI.

The problem is that when we fed 'eevee' to name afterwards, we still don't get any logs on the console. So, what went wrong?


linkIn Depth Look

To understand the situation, lets recall what Observables basically are:

An Observable is sorta-kinda like a function. To be more precise, its like a push function that generates multiple values (according to Rxjs's docs).

In contrast, a normal function is a pull function that generates one value.

If an Observable is like a function, then a Subscription is its equivalent of a function call. The same way you need to call a function to get its value, you need to subscribe to an observable to start getting its values:

1name.pipe(switchMap(name => ajax.getJSON(POKE_API + name + '/'))) // --> This is the `Observable`, or the function

2.subscribe(d => // --> This is the `Subscription`, or the function call

3 console.log( // --> This is the `Subscription`, or the function call

4 `${d.name}:: ` + // --> This is the `Subscription`, or the function call

5 `${d.abilities.map(a => a.ability.name).join(', ')}` // --> This is the `Subscription`, or the function call

6 )

7);

When an unhandled error happens in a function call, that particular function call terminates.
Similarly, when an unhandled error happens in a Subscription, that Subscription terminates.

In our code, we have ONE subscription to name.pipe(...), so when an error occurs in it, it terminates:

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

  1. name emits 'charizard', its initial value, so our subscription receives charizard's info from API.

  2. name emits 'snorlax', so our subscription receives snorlax's info from API.

  3. name emits 'ZZZ', and our subscription receives an error and terminates.

  4. name doesn't even emit 'eevee' because there are no subscriptions to emit to.


linkNaive Error Handling

If it was imperative programming, we would simply enclose the whole thing in a try/catch block, so lets do the RxJS equivalent of that:

1import { ajax } from 'rxjs/ajax';

2import { BehaviorSubject, of } from 'rxjs';

3import { switchMap, catchError } from 'rxjs/operators'; // --> Also import `catchError`

4

5const POKE_API = 'https://pokeapi.co/api/v2/pokemon/';

6

7const name = new BehaviorSubject('charizard');

8name.pipe(

9 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

10 catchError(() => of({ // --> So when there is an error ...

11 name: 'unknown', // --> ... Return an `unknown` Pokemon ...

12 abilities: [] // --> ... With no abilities.

13 }))

14).subscribe(d =>

15 console.log(

16 `${d.name}:: ` +

17 `${d.abilities.map(a => a.ability.name).join(', ')}`

18 )

19);

Try It!

Now lets run it against our failing test case again:

1setTimeout(() => name.next('snorlax'), 1000); // --> snorlax info is fetched

2setTimeout(() => name.next('ZZZ'), 1000); // --> ZZZ does not exist

3setTimeout(() => name.next('eevee'), 3000); // --> eevee info is also not fetched!

4

5// Result:

6// > charizard:: solar-power, blaze

7// > snorlax:: gluttony, thick-fat, immunity

8// > unknown::

9// No more logs


We get the unknown:: log, which means we are catching the error and handling it. However, we are still not getting any response to 'eevee'. Why is that?

First, lets recall what RxJS pipes are:

A pipe is simply a function that transforms one Observable to another.
x.pipe(a, b, c) is basically equivalent to

1y = x.pipe(a);

2z = y.pipe(b);

3w = z.pipe(c);

So this code:

1name.pipe(switchMap(...), catchError(...)).subscribe(...)

is basically equivalent to this code:

1x = name.pipe(switchMap(...))

2y = x.pipe(catchError(...))

3y.subscibe(...)

Or this code:

1 x = switchMap(...)(name);

2 y = catchError(...)(x);

3 y.subscribe(...);

When you subscribe to y, it internally subscribes to x and passes down values it receives from that inner subscription to your outer subscription.

When an error occurs in that inner subscription, it will naturally terminate.

However, catchError() wants to maintain the outer subscription, so it calls the factory function you provide it (() => of(...) in this case), and creates another inner subscription to the result of this function (which should have returned an observable), now feeding the outer subscription from this new inner subscription.

In other words, what happens here is:

1name.pipe(

2 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

3 catchError(() => of({

4 name: 'unknown',

5 abilities: []

6 }))

7).subscribe(...);

8

9setTimeout(() => name.next('snorlax'), 1000);

10setTimeout(() => name.next('ZZZ'), 1000);

11setTimeout(() => name.next('eevee'), 3000);

  1. You are originally subscribed to name (and the switchMap()) via catchError().

  2. name emits 'ZZZ', switchMap() throws an error, the inner subscription to it is terminated.

  3. To mitigate, catchError() calls () => of(...) to create a new inner subscription as the source of your outer subscription.

  4. Now you are basically subscribed to of(...) which emits once and terminates.
    Note that at this point, YOU ARE NO LONGER SUBSCRIBED TO name.

  5. name doesn't even emit 'eevee' as there are no subscriptions to emit to.

linkWhy So Weird?

This might seem confusing and weird, however this is exactly how normal functions would behave. Basically, catchError() would be a function like this if we were working with normal functions instead of observables:

1function catchError(handlerFactory) {

2 return function(ogFunc) {

3 return (...args) => { // --> the outer function call (like the outer subscription)

4 try {

5 return ogFunc(...args); // --> the inner function call (like the inner subscription)

6 } catch(error) {

7 return handlerFactory(error)(...args); // --> the replacement inner function call (like the replacement inner subscription)

8 }

9 }

10 }

11}

1x = function() { ... }; // --> the original function

2y = catchError(...)(x); // --> the catchError pipe

3y(...); // --> the function call

1x = ... // --> the original observable

2y = catchError(...)(x); // --> the catchError pipe

3y.subscribe(...); // --> the subscription

The difference however, is that from a normal function, we only expect ONE value. So in case of error, we can simply replace it with another ONE value.

Observables on the other hand, can (and are expected to) push multiple values. In our case, we literally expect our subscription to keep getting values in response to future events, while we are replacing it with a one-off subscription (to of(...)).


linkThe Fix

A neat solution would be to conduct the error handling closer to its source.

In our example, this source (fortunately) is not the long-living subscription to name itself, but rather the short-living one-off subscriptions to ajax.getJSON(...) that we create for every emission of name.

Because these subscriptions are supposed to be short-lived themselves (each one is supposed to respond with ONE value), we can safely replace them with another one-off subscription in case of error:

1name.pipe(

2 switchMap(

3 name => ajax.getJSON(POKE_API + name + '/').pipe( // --> so `catchError()` is directly piped to `ajax.getJSON()`

4 catchError(() => of({ // --> so `catchError()` is directly piped to `ajax.getJSON()`

5 name: 'unknown', // --> so `catchError()` is directly piped to `ajax.getJSON()`

6 abilities: [] // --> so `catchError()` is directly piped to `ajax.getJSON()`

7 })) // --> so `catchError()` is directly piped to `ajax.getJSON()`

8 ) // --> so `catchError()` is directly piped to `ajax.getJSON()`

9 ),

10).subscribe(d =>

11 console.log(

12 `${d.name}:: ` +

13 `${d.abilities.map(a => a.ability.name).join(', ')}`

14 )

15);

Try It!

Now this sequence would behave like this in our test case:

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

4

5// Result:

6// > charizard:: solar-power, blaze

7// > snorlax:: gluttony, thick-fat, immunity

8// > unknown::

9// > eevee:: anticipation, adaptability, run-away


linkRetrying

What about situations where the source of the error IS a long-living subscription?

In that case, when our long living subscription terminates due to an error, we could actually replace it by another subscription to the same long living observable.

The retry() operator does exactly that:

1import { ajax } from 'rxjs/ajax';

2import { BehaviorSubject } from 'rxjs';

3import { switchMap, retry } from 'rxjs/operators'; // --> Now we are importing `retry` as well

4

5const POKE_API = 'https://pokeapi.co/api/v2/pokemon/';

6

7const name = new BehaviorSubject('charizard');

8name.pipe(

9 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

10 retry(), // --> In case of error, simply retry

11).subscribe(d =>

12 console.log(

13 `${d.name}:: ` +

14 `${d.abilities.map(a => a.ability.name).join(', ')}`

15 )

16);

Try It!

touch_app FUN FACT

You could actually replicate behavior of retry() using catchError():

1function myRetry(observable) {

2 return observable.pipe(catchError(() => myRetry(observable)));

3}

1name.pipe(switchMap(...), myRetry).subscribe(...);


On the first glance, this approach seems to cleanly solve our issue:

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

4

5// > charizard:: solar-power, blaze

6// > snorlax:: gluttony, thick-fat, immunity

7// > eevee:: anticipation, adaptability, run-away


However, if we add a console log before each request, we can see that we are actually messing up pretty terribly:

1name.pipe(

2 tap(value => console.log(`REQUEST FOR ${value}`)),

3 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

4 retry(),

5).subscribe(...);

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

4

5// > REQUEST FOR charizard

6// > charizard:: solar-power, blaze

7// > REQUEST FOR snorlax

8// > snorlax:: gluttony, thick-fat, immunity

9// > REQUEST FOR ZZZ

10// > REQUEST FOR ZZZ

11// > REQUEST FOR ZZZ

12// > REQUEST FOR ZZZ

13// > REQUEST FOR ZZZ

14// > REQUEST FOR ZZZ

15// ...

16// ... about 100 times or more

17// ...

18// > REQUEST FOR ZZZ

19// > REQUEST FOR ZZZ

20// > REQUEST FOR ZZZ

21// > REQUEST FOR eevee

22// > eevee:: anticipation, adaptability, run-away

linkRe-Subscription Loop

What happened?

Well, everytime our ajax.getJSON(...) subscription fails, retry() will re-subscribe to its previous observable, which means it is indirectly re-subscribing to name as well.

name is a BehaviorSubject, which means when you subscribe to it, it will immediately emit its latest value to you, which in this case is 'ZZZ'.

As a result, immediately after each time we get an error, we re-subscribe to name, get 'ZZZ' again, make a request for it, fail, and repeat this cycle.

Note that after about one second, 'eevee' is emitted by name, which will take us out of this loop. If it wasn't for that emission, we would be stuck in this loop indefinitely.

linkBreaking the Loop

To break out of this cycle, we can use retryWhen() instead of retry():

1name.pipe(

2 tap(x => console.log(`REQUEST FOR ${x}`)),

3 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

4 retryWhen(() => name), // --> using `retryWhen()` instead of `retry()`

5).subscribe(...);

Try It!

retryWhen() basically retries when the observable returned by the function passed to it emits its next value. In our case, this means we will retry (re-subscribe) when name emits a value:

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

4

5// > REQUEST FOR charizard

6// > charizard:: solar-power, blaze

7// > REQUEST FOR snorlax

8// > snorlax:: gluttony, thick-fat, immunity

9// > REQUEST FOR ZZZ

10// > REQUEST FOR ZZZ

11// > REQUEST FOR eevee

12// > eevee:: anticipation, adaptability, run-away

Note that 'ZZZ' is still being tried two times. That is because when the first try causes an error, retryWhen() subscribes to name as its notifier, which immediately emits 'ZZZ' once more, causing the second try.


Alternatively, we could keep using retry() and make name a Subject instead of a BehaviorSubject. In that case, it would emit each value only once and to subscriptions present at the time, so when we re-subscribe to it after an error, we won't get the problematic value again:

1const name = new Subject();

2name.pipe(

3 tap(x => console.log(`REQUEST FOR ${x}`)),

4 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

5 retry(),

6).subscribe(...);

1setTimeout(() => name.next('snorlax'), 1000);

2setTimeout(() => name.next('ZZZ'), 1000);

3setTimeout(() => name.next('eevee'), 3000);

4

5// > REQUEST FOR snorlax

6// > snorlax:: gluttony, thick-fat, immunity

7// > REQUEST FOR ZZZ

8// > REQUEST FOR eevee

9// > eevee:: anticipation, adaptability, run-away

warning CAREFUL THOUGH ...

Using retryWhen() in combination with Subject wouldn't actually work:

1const name = new Subject();

2name.pipe(

3 tap(x => console.log(`REQUEST FOR ${x}`)),

4 switchMap(name => ajax.getJSON(POKE_API + name + '/')),

5 retryWhen(() => name)

6).subscribe(...)

This is due to the fact that we do not re-subscribe until name emits another value after the problematic 'ZZZ'. The next value is 'eevee', so we retry (re-subscribe) AFTER it was emitted, meaning that we would basically miss it.



Hero Image by Sebastian Herrmann from Unsplash.

Hero Image by Mitchell Luo from Unsplash.

In Depth LookNaive Error HandlingWhy So Weird?The FixRetryingRe-Subscription LoopBreaking the Loop

Home

On Reactive Programmingchevron_right
Yet Another Frontend Frameworkchevron_right
Other Articleschevron_right
